Description
3 5/6 Dual Display DMM w/USB Connector
Vəziyyəti : Yeni
Anbarda qalan : 10
- 3 5/6 digits 5999 counts, 0.5% best accuracy.
- Auto/Manual both range.
- Dual display with analog bargraph.
- Extra functions: duty cycle, relative reference, Max/Min hold, data hold, auto power off, low battery indication.
| Specification | |
| DCV | 600m/6/60/600V ±(0.5%+4d), 1000V ±(1.0%+6d) |
| ACV | 6/60/600V ±(0.8%+10d), 750V ±(1.0%+10d) |
| DCA | 600μ/6000μA ±(1.0%+10d), 60m/600mA ±(1.0%+10d), 6/10A ±(1.2%+10d) |
| ACA | 600μ/6000μA ±(1.5%+10d), 60m/600mA ±(1.5%+10d), 6/10A ±(2.0%+15d) |
| Resistance | 600Ω ±(0.8%+5d), 6k/60k/600k/6MΩ ±(0.8%+4d), 60MΩ ±(1.2%+10d) |
| Frequency | 100/1000Hz ±(0.5%+4d), 10k/100kHz ±(0.5%+4d), 1M/30MHz ±(0.5%+4d) |
| Capacitance | 40nF±(5%+30d), 400n/4μ/40μF±(3.5%+8d) 200μF±(5.0%+10d) |
| Temperature | -20~400˚C(0~750˚F) ±(1.0%+5d), 400~1000˚C(750~1832˚F) ±(1.5%+15d) |
| Continuity with buzzer |
Y |
| Diode test | Y |
| Transistor test | Y |
| Power source | AAA(1.5V)×2pcs (Not included) |
| Size | 192×95×48 mm |
| Individual Packing | Color box |
